Battery Operated Acetabular Reaming System, Battery Operated Acetabular Reaming System Manufacturer, Battery Operated Acetabular Reaming System Suppliers, Orthopedic Implants, India

SPT1437 Battery Operated Acetabular Reaming System AO Types (2G SERIES)

Zoom

Specifications :

Power Output : ≥ 65W
Speed : 0-280(r.p.m)
Torque : 5.5Nm
Noise : ≤ 40 (db)
Battery : 9.6 (V), Ni-Mh, 1800 mA/h
Sterilization : 135° C
Usage: Joint Operation. High torque, Low speed, stepless variable speed control.

Set Consisting of :	Units
SPT1437.1 - Battery powered handpiece with AO/Synthes Reamer Adapter	1
SPT141 - Battery	2
SPT142 - Battery Charger 220V, 50Hz	1
SPT143 - Sterilizing Ring	2
SPT144 - Jacub Chuck & Key	1
OPTIONAL ADAPTERS (To be Ordered Separately at Extra Cost)
SPT08 - Hudson Adapter
SPT09 - Zimmer Adapter
SPT10 - Link Adapter
SPT11 - Aesculup Adapter
SPT12 - Stryker Adapter

SPT1438 Battery Operated Acetabular Reaming System (2G SERIES)

Same as SPT37 but with Stryker Reamer Adapter
To be Ordered Separately at Extra Cost
SPT37.2 - Acetabulum Reamer Shaft (AO/Synthes Type)
SPT38.2 - Acetabulum Reamer Shaft (Stryker Type)
OPTIONAL ADAPTERS (To be Ordered Separately at Extra Cost)
SPT13 - Link Adapter
SPT14 - Aesculup Adapter
SPT15 - AO/Synthes Adapter

SPT37 Battery Operated Acetabular Reaming System AO Types (4G SERIES)

Zoom

Same as SPT1437 but with below specifications

Specifications :

Power Output : ≥85W
Speed : 0-320(r.p.m)
Torque : 7.8 Nm
Noise : ≤ 40 (db)
Battery : 14.4 (V), Ni-Mh, 1800 mA/h
Sterilization : 155° C
Usage: Joint Operation. High torque, Low speed, stepless variable speed control.

Set Consisting of :	Units
SPT37.1 - Battery powered handpiece with AO/Synthes Reamer Adapter	1
SPT01 - Battery	2
SPT02 - Battery Charger 220V, 50Hz	1
SPT03 - Sterilizing Ring	2
SPT04 Jacub Chuck & Key	1

SPT38 Battery Operated Acetabular Reaming System (4G SERIES)

Same as SPT37 but with Stryker Reamer Adapter
To be Ordered Separately at Extra Cost
SPT37.2 - Acetabulum Reamer Shaft (AO/Synthes Type)
SPT38.2 - Acetabulum Reamer Shaft (Stryker Type)
OPTIONAL ADAPTERS (To be Ordered Separately at Extra Cost)
SPT13 - Link Adapter
SPT14 - Aesculup Adapter
SPT15 - AO/Synthes Adapter

SPT637 Battery Operated Acetabular Reaming System, High Torque / High Power (6G SERIES)

Zoom

Same as SPT1437 but with below specifications

Specifications :

Power Output : ≥ 95W
Speed : 0-350(r.p.m)
Torque : 9.0Nm
Noise : ≤ 40 (db)
Battery : 14.4 (V), Ni-Mh, 1800 mA/h
Sterilization : 135° C
Usage: Joint Operation. High torque, Low speed, stepless variable speed control.

Set Consisting of :	Units
SPT637.1 - Battery powered handpiece with AO/Synthes Reamer Adapter	1
SPT61 - Battery	2
SPT62 - Battery Charger 220V, 50Hz	1
SPT63 - Sterilizing Ring	2
SPT64 - Jacub Chuck & Key	1

SPT638 Battery Operated Acetabular Reaming System, High Torque / High Power (6G SERIES)

Zoom

Same as SPT637 but with Stryker Reamer Adapter

To be Ordered Separately at Extra Cost
SPT37.2 - Acetabulum Reamer Shaft (AO/Synthes Type) for SPT37, SPT637 & SPT1437
SPT38.2 - Acetabulum Reamer Shaft (Stryker Type) for SPT38, SPT638 & SPT1438

Acetabulum Reamer (AO/Synthes Type): SPT37.036 to SPT37.064
Code No.	Size mm	Code No.	Size mm	Code No.	Size mm
SPT37.036	36	SPT37.046	46	SPT37.056	56
SPT37.038	38	SPT37.048	48	SPT37.058	58
SPT37.040	40	SPT37.050	50	SPT37.060	60
SPT37.042	42	SPT37.052	52	SPT37.062	62
SPT37.044	44	SPT37.054	54	SPT37.064	64

Acetabulum Reamer (Stryker Type): SPT38.036 to SPT38.064
Code No.	Size mm	Code No.	Size mm	Code No.	Size mm
SPT38.036	36	SPT38.046	46	SPT38.056	56
SPT38.038	38	SPT38.048	48	SPT38.058	58
SPT38.040	40	SPT38.050	50	SPT38.060	60
SPT38.042	42	SPT38.052	52	SPT38.062	62
SPT38.044	44	SPT38.054	54	SPT38.064	64

OPTIONAL Adapters for SPT37, SPT637 & SPT1437 (To be Ordered Separately at Extra Cost)
SPT08 - Hudson Adapter
SPT09 - Zimmer Adapter
SPT10 - Link Adapter
SPT11 - Aesculup Adapter
SPT12 - Stryker Adapter

OPTIONAL Adapters for SPT38, SPT638 & SPT1438 (To be Ordered Separately at Extra Cost)
SPT13 - Link Adapter
SPT14 - Aesculup Adapter
SPT15 - AO/Synthes Adapter
